Pin
Type
A21
Output
NENC_T
A22
Input
A28
Output
A29
Output
A32
Input
A33
Input
4.2.5 Dual BL traction with sin/cos sensor
When the inverter is configured as DUALBLE2 NEW GENERATION for
controlling two traction brushless motors equipped with sin/cos sensors as speed
and position feedback, the pinout differs from that of the dual AC traction
configuration only for the pins listed in the following table. The other ones are
unchanged both in name and in function (see paragraph 4.2.3).
Pin
Type
A1
Input
A4
Output
A9
Input
A10
Output
PSENS_R
A14
Input
A15
Output
A17
Input
Page 36/169
COMBIACE2 NEW GENERATION (traction + pump)
Name
Description
Negative supply for the traction encoder, the traction side
thermal sensor and potentiometers.
Analog input 4.
CPOT
LIFT
The default function is as lift reference.
Driving output for the traction electromechanical brake (driving
NEB_T
to -B); PWM controlled; 3 A maximum continuous current.
Driving output for an auxiliary electrovalve (driving to -B); PWM
NAUX
controlled; 3 A maximum continuous current.
Analog input for the thermal sensor of the traction motor.
PTH_T
Internal pull-up is a 2 mA current source (max 5 V).
Analog input for the thermal sensor of the pump traction motor.
PTH_P
Internal pull-up is a 2 mA current source (max 5 V).
DUALBLE2 NEW GENERATION with sin/cos sensors
Name
Description
Analog input 4.
CPOT
The default function is as steering reference (wiper contact of
STEER
the steering potentiometer).
Positive supply for the left-hand side sin/cos sensor and for
PSENS_L
potentiometers (+5 V or +12 V, 200 mA maximum).
Digital input, active when connected to -B.
SPARE
The default function is not defined.
Positive supply for the right-hand side sensor and for
potentiometers (+5 V or +12 V, 200 mA maximum).
SIN_R
Sine signal of the right-hand side sin/cos sensor.
Negative supply for the left-hand side sin/cos sensor, the left-
NSENS_L
hand side thermal sensor and potentiometers.
Digital input, active when connected to -B.
SPARE
The default function is not defined.
AFNZPxxx – DUALACE2 NEW GENERATION – User Manual
