8.2.8 SLV HW Setting
Parameter
S FEEDBACK SENS.
(A)
S ROT. CW ENC
(A)
S ROT CW MOT
(A)
S ENC PULSES 1
(A)
AFNZPxxx– DUALACE2 NEW GENERATION – User Manual
HARDWARE SETTING
Allowable range
0 ÷ 6
OPTION#1 ÷ OPTION#2
OPTION#1 ÷ OPTION#2
32 ÷ 1024
Description
This parameter defines the type of the adopted speed
sensor for motor 2. Factory adjusted.
0 = Incremental encoder.
1 = Sin/cos sensor.
2 = Incremental encoder + sin/cos sensor.
3 = Incremental encoder + sin/cos sensor + index.
4 = PWM absolute sensor + incremental encoder +
index.
5 = Resolver.
6 = Hall effect sensor (six-step).
It defines how the signal sequence coming from the
encoder channels is expected by controller 2
OPTION#1 = Channel A anticipates channel B.
OPTION#2 = Channel B anticipates channel A.
It permits to change the sequence in which the motor 2
phases are powered. Factory adjusted.
OPTION#1 = U-V-W corresponds to forward direction.
OPTION#2 = V-U-W corresponds to forward direction.
This parameter defines the number of encoder pulses per
revolution (motor 2). It must be set equal to ENCODER
PULSES 2; otherwise the controller raises an alarm.
The available options are:
25
32
124
128
NOTE: with standard HW, the capability to use encoders
with high number of pulses could be limited depending on
the speed. Ask to Zapi technician before to operate on this
parameter
48
64
80
256
512
1024
Page 95/169
