4 I/O INTERFACE DESCRIPTION
4.1 Power connectors
Power connections are on vertical posts where to bolt power-cables lugs. On the
cover of the converter they are labeled as follows.
Terminal name
+B, -B
UM, VM, WM
US, VS, WS
4.2 Ampseal connector
4.2.1 Standard version
DUALACE2 NEW GENERATION Standard is equipped with a 23-poles Ampseal
connector like that of the figure. Each of the 23 pins is referred to as "A#", where
"A" denotes the connector name and "#" the pin number, from 1 to 23.
For each I/O pin, the default Zapi function is indicated. The function of each pin
can be changed in the customized software.
Some I/O pins can have special functionality depending on controller
configuration.
Pin
Type
Input
A1
Output
PENC_L
A2
Page 30/169
Battery terminations
Motor 1 phase terminations.
Motor 2 phase terminations.
23-poles Ampseal connector of DUALACE2 NEW GENERATION Standard.
DUALACE2 NEW GENERATION Standard
Name
KEY
Input of the key switch signal.
Positive supply for the left-hand side encoder and for
potentiometers (+5 V or +12 V, 200 mA maximum).
Description
Description
AFNZPxxx – DUALACE2 NEW GENERATION – User Manual
