Description above is valid for every menu which contains parameters and options
like SET OPTIONS, ADJUSTMENT, HARDWARE SETTINGS, etc.
13.2.6 PROGRAM VACC
PROGRAM VACC menu has been slightly modified from old consoles.
Upon entering this menu the console shows the current programmed values.
When OK is pressed, PROGRAM VACC procedure starts. Console invites you:
Displayed values vary accordingly to operator inputs.
Sequence above can slightly vary depending on controller firmware. Anyway the
logic remains the same: before programming the min/max values, execute any
starting sequence which is necessary, then press the pedal or push the joystick.
Page 164/169
to select the enable switch, if any;
to select the direction switch (either forward or backward);
to depress the pedal to its maximum excursion.
AFNZPxxx – DUALACE2 NEW GENERATION – User Manual
