Zapi DUALACE2 NEW GENERATION User Manual page 98

Table of Contents

Advertisement

Parameter
IQIMAX LIM. TRA
(A)
IQIMAX LIM. BRK
(A)
MOT. POWER WATT
(A)
STATOR FLUX MWB
(A)
MOTION TORQUE NM
(A)
STEER ANGLE
(A)
TEMPERATURE
(A)
TEMPERATURE SLV
(A)
MOTOR TEMPERAT.
(A)
DI2-A8 SEAT SW
(D, C)
DI3-A13 QI/PB SW
(D, C)
DI0-A6 FW SW
(D, C)
DI1-A7 BW SW
(D, C)
DI0-A6 ENABLE
(D, C)
DI7-A2 SR/HB
(D, C)
Page 98/169
TESTER (Master µC)
Unit of measure
(resolution)
Ampere (1 A)
Ampere (1 A)
Watt (1 W)
-3
10
Weber (0.1 mWb)
Nm (0.1 Nm)
Degrees (1°)
Celsius degrees (1 °C)
Celsius degrees (1 °C)
Celsius degrees (1 °C)
OFF/ON
OFF/ON
OFF/ON
OFF/ON
OFF/ON
OFF/ON
AFNZPxxx – DUALACE2 NEW GENERATION – User Manual
Description
Maximum value of the q-axis current component,
according to traction-related settings, expressed in
root-mean-square Ampere
Maximum value of the q-axis current component,
according to braking-related settings, expressed in
root-mean-square Ampere.
Estimation of the power supplied to the motor.
Estimation of the motor magnetic flux.
Estimation of the motor torque.
Current steering- wheel angle. When the steering is
straight ahead STEER ANGLE is zero.
Temperature measured on the inverter base plate.
This temperature is used for the HIGH TEMPERATURE
alarm.
Temperature measured on the inverter base plate.
This temperature is used for the HIGH TEMPERATURE
alarm.
Motor-windings temperature.
Normally the sensor is a PTC Philips KTY84-130. This
temperature is used for the MOTOR OVERTEMP alarm.
Status of the TILLER/SEAT input
Status of the quick-inversion/pedal-brake input
Status of the forward-request input
Status of the backward-request input
Status of the lowering-request input
Status of the speed-reduction/hand-brake input A2.
A8
(A6).
A17
(A11).
A6
(A4).
A7
(A5).
A6
(A4).
