Pin
Type
A33
Input
A34
Input
A35
Input
4.2.4 Combi AC configuration (traction + pump)
When the inverter is configured as COMBIACE2 NEW GENERATION for
controlling one traction motor and one pump motor, the pinout differs from that of
the dual traction configuration only for the pins listed in the following table. The
other ones are unchanged both in name and in function (see paragraph 4.2.3).
Pin
Type
A2
Input
A4
Output
PENC_P
A9
Input
A10
Output
A12
Input
A15
Output
NENC_P
A17
Input
A19
Input
A20
Input
AFNZPxxx– DUALACE2 NEW GENERATION – User Manual
DUALACE2 NEW GENERATION (dual traction)
Name
Description
Analog input for the thermal sensor of the left-hand side
traction motor.
PTH_L
Internal pull-up is a 2 mA current source (max 5 V).
Analog input 5.
CPOT5
The default function is not defined.
Analog input 6.
CPOT6
The default function is not defined.
COMBIACE2 NEW GENERATION (traction + pump)
Name
Description
Digital input, inactive when connected to -B, active when the
SR/HB/
switch is open.
HYDRO
The default function is as hydro request.
Positive supply for the pump encoder and for potentiometers
(+5 V or +12 V, 200 mA maximum).
CHA_T
Channel A of the traction incremental encoder.
Positive supply for the traction encoder and for potentiometers
PENC_T
(+5 V or +12 V, 200 mA maximum).
Digital input, active when connected to -B.
LIFT
The default function is as lift request; closing this input the
pump is activated.
Negative supply for the pump encoder, the pump thermal
sensor and potentiometers.
CHA_P
Channel A of the left-hand side incremental encoder.
CHB_P
Channel B of the pump incremental encoder.
CHB_T
Channel B of the traction incremental encoder.
Page 35/169
