8.2.2 Valve output
Parameter
EVP TYPE
(A)
EVP COIL RESIST.
(A)
MIN EVP
(A)
MAX EVP
(A)
EVP OPEN DELAY
(A)
EVP CLOSE DELAY
(A)
DITHER AMPLITUDE
(A)
DITHER FREQUENCY
(A)
Page 74/169
PARAMETER CHANGE
Allowable range
NONE ÷ ANALOG
0 ÷ 255
(steps of 1/255)
0% ÷ 100%
(steps of 1/255)
0% ÷ 100%
(steps of 1/255)
0 s ÷ 12.75 s
(steps of 0.05 s)
0 s ÷ 12.75 s
(steps of 0.05 s)
0% ÷ 13%
20.8 Hz ÷ 83.3 Hz
AFNZPxxx – DUALACE2 NEW GENERATION – User Manual
Description
This parameter defines the behavior of output EVP
NONE = Output
A25
is not enabled.
DIGITAL = Output
A25
manages an on/off valve
ANALOG = Output
A25
current-controlled proportional valve.
This parameter defines the resistance of the coil
connected to EVP output (A25).
It is expressed in Ohm
This parameter determines the minimum current applied to
the EVP when the potentiometer position is at the
minimum. This parameter is not effective if the EVP is
programmed like an on/off valve.
This parameter determines the maximum current applied
to the EVP when the potentiometer position is at the
maximum. This parameter also determines the current
value when the EVP is programmed like an ON/OFF valve.
It determines the current increase rate on EVP. The
parameter sets the time needed to increase the current to
the maximum possible value.
It determines the current decrease rate on EVP. The
parameter sets the time needed to decrease the current
from the maximum possible value to zero.
This parameter defines the dither signal amplitude. The
dither signal is a square wave added to the proportional-
valve set-point. In this way the response to set-point
variations results optimized. This parameter is a
percentage of the valve maximum current. Setting the
parameter to 0% means the dither is not used.
The available values are:
0.0%, 1.0%, 2.5%, 4.0%, 5.5%, 7.0%, 8.5%, 10%,
11.5%, 13.0%
This parameter defines the dither frequency.
The available values are:
20.8, 22.7, 25, 27.7, 31.2, 35.7, 41.6, 50, 62.5, 83.3
manages a PWM-modulated
A25
