Pin
Type
A19
Input
A20
Input
A21
Output
NSENS_R
4.3 Internal connector
Pin
Type
1
-
2
Input
3
Output
4
Output
5
Output
6
Output
7
Input
8
Input
4.4 External devices
4.4.1 Key input
KEY input
supplies battery voltage to the logic circuitry and it also pre-charges the DC-link
capacitors at key-on, before main contactor closes. The KEY voltage is
monitored.
Note: external loads connected to the power terminal +B, such as proximity
switches, load the internal PTC resistor along the key input path, with the
consequence that the pre-charge voltage may be lower than expected.
Page 38/169
DUALBLE2 NEW GENERATION with Hall sensors
Name
Description
SH3_L
Third left-hand side Hall sensor.
SH3_R
Third right-hand side Hall sensor.
Negative supply for the right-hand side Hall sensors, the right-
hand side thermal sensor and potentiometers.
Name
Description
-
Not used: it can be unconnected.
NCLRXD Negative serial reception.
PCLTXD
Positive serial transmission.
NCLTXD
Negative serial transmission.
GND
Negative console power supply.
+15
Positive console power supply.
FLASH
It must be connected to pin 8 for the Flash memory
programming.
FLASH
It must be connected to pin 7 for the Flash memory
programming.
A3
(A1) is generally connected to the vehicle start key switch. It
