12.7

AT+CGSETV Set the value of specified GPIO

Description
This command is used to set the value of the specified GPIO to high or low.
SIM PIN References
NO Vendor
Syntax
Test Command
AT+CGSETV=?
Write Command
AT+CGSETV=<GPIO>,<gp
io_hl>
Defined values
<GPIO>
The value is GPIO ID, different hardware versions have different values.
<gpio_hl>
0 – low
1 – high
Examples
AT+CGSETV=43,0
OK
12.8

AT+CGGETV Get the value of specified GPIO

Description
This command is used to get the value (high or low) of the specified GPIO.
SIM PIN References
NO Vendor
Syntax
SIM7500_SIM7600 Series_AT Command Manual_V1.07
Responses
+CGSETV: (list of supported <GPIO>s),(list of supported
gpio_hl >s)
OK
Responses
OK
ERROR
