TotalAlert Infinity™ HTM Medical Gas Notification System
Typical Retrofit Layouts
(Recommended Installation)
Module Components
Letter
Description
Designator
A
B05 Power Supply
B
B30 Module (Signals, 20 Inputs)
C
B60 Module (Gas Input, 8 gases, 1 output)
Dimensions
232mm
4107 9016 60.01
A
B
282mm
MP125 Retrofit
282mm
MP26 Retrofit
5-4
232mm
A
C
