TotalAlert Infinity™ HTM Medical Gas Notification System
Recommended separation distances between
portable and mobile RF communications equipment and the TotalAlert Infinity
The TotalAlert Infinity is intended for use in the electromagnetic environment in which radiated
RF disturbances are controlled. The customer or the user of the TotalAlert Infinity can help
prevent electromagnetic interference by maintaining a minimum distance between portable
and mobile RF communications equipment (transmitters) and the TotalAlert Infinity as recom-
mended below, according to the maximum output power of the communications equipment.
Rated maximum output
power of transmitter
W
0,01
0,1
1
10
100
For transmitters rated at a maximum output power not listed above, the recommended sepa-
ration distance d in metres (m) can be estimated using the equation applicable to the frequency
of the transmitter, where P is the maximum output power rating of the transmitter in watts (W)
according to the transmitter manufacturer.
Note 1 At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies.
Note 2 These guidelines may not apply in all situations. Electromagnetic propagation is affected
by absorption and reflection from structures, objects and people.
1.7 TotalAlert Infinity™ Medical Gas Notification System Parent Model
Number Chart
A3 - ___
B
Variable B
Alarm Type and Size
Allowable Description
Value
A10 Area Alarm, Up to 8 Area Gases
M01 Central, 0 Inputs, 16 Relay Outputs
M02 Central, 0 Inputs, 32 Relay Outputs
M10 Central, 20 Inputs
M11 Central, 20 Inputs, 16 Relay Outputs
C10 Combination, 20 Inputs, Display up to
6 Area Gases
C40 Combination, 4 Inputs for 4-20 mA
devices, 6 Relay Outputs
Separation distance according to frequency of transmitter
150 kHz to
80 MHz to 800 MHz
80 MHz
d = 1,2√P
d = 1,2√P
0,12 0,12
0,38 0,38
1,2 1,2
3,8 3,8
12 12
m
800 MHz to 2,5 GHz
d = 2,3√P
0,23
0,73
2,3
7,3
23
Available Gas Sensors
Description
Oxygen
Nitrous Oxide
Medical Air
Medical Vacuum
Nitrogen
Carbon Dioxide (CO2)
HE-O2 (HE over 80%)
Laboratory Air
Laboratory Vacuum
Surgical Air
O2-N2O
Example: TotalAlert Infinity™ Central Alarm with 20 Inputs and 16 Relay
Outputs Example Model Number:
Example: TotalAlert Infinity™ Area Alarm with 4 gases - Oxygen, Nitrous
Oxide, Medical Air, and Vacuum
Example Model Number:
* Gas sensors to be ordered separately
Example: TotalAlert Infinity™ Combination Alarm with 20 Inputs, and 3
gases - Oxygen, Medical Air, and Vacuum
Example Model Number:
* Gas sensors to be ordered separately
Example: TotalAlert Infinity™ Combination Alarm with four 4-420mA
devices and 6 Relay Outputs.
Example Model Number:
1-9
A3-M11
A3-A10
A3-C10
A3-C40
