TotalAlert Infinity™ HTM Medical Gas Notification System

4.4.3 Maintenance Mode Setup

To ensure the audible warning does not sound while
setting up the alarm, the MAINTENANCE MUTE function
can be activated.
Touch the MISCELLANEOUS tab in the configuration
menu.
Figure 67: Miscellaneous Tab
Touch the AUDIBLE SETTINGS tab.
Figure 68: Audible Settings Tab
Press the tab to turn maintenance mode on. Exit the
screens to return to the configuration screen.
Figure 69: Maintenance Mode ON
4107 9016 60.01
NOTE:
See the end of this section for information on the
Miscellaneous Tab. See Section 4.6 for information
on the Active Alarm Opt Tab.
Figure 70: Combination Alarm Main Screen
4.5 Setting up a Combination
Alarm
The TotalAlert Infinity
the functionality of a Area alarm and a central alarm. It
monitors two things:
• Gases and their pressures.
• Source equipment.
4.5.1 Initial Setup of an Unconfigured
Combination Alarm
To begin setup of the alarm, first pull the battery tab
located on the back of the front panel to activate
battery backup of the alarm.
Figure 71: Battery Pull Tab
4-20
combination alarm combines
™
