- Page 1 Installation, Operation and Maintenance Instructions Medical Vacuum Filter Modules Part number 4107 9022 25.00 24 July 2018...
- Page 3 Installation, Operation and Maintenance Manual Medical Vacuum Filter Modules This unit is purchased from: Date purchased: Model number: Serial number: Option(s) included: Any information, service or spare parts requests should include the machine serial number and be directed to: BeaconMedæs 1059 Paragon Way Rock Hill, SC 29730 Telephone: (888) 463-3427...
-
Page 4: Table Of Contents
Medical Vacuum Filter Modules Table of Contents 1.0 Introduction ..............1-1 1.1 Audience ......................1-1 1.2 Definition of Statements ................1-1 1.3 Product Description ..................1-1 1.4 Environmental Considerations ..............1-1 1.5 Environmental Declarations ................ 1-1 2.0 Installation ...............2-1 2.1 Inspection Upon Receiving ................2-1 2.2 Handling ......................2-1 2.3 Location ...................... -
Page 5: Introduction
Medical Vacuum Filter Modules 1.0 Introduction Environmental Declarations Audience Disposal This manual provides information related to General the installation, operation, and maintenance of the Medical Vacuum (MV) Filter Modules manu- When developing products and services, Bea- factured by BeaconMedæs. Service information conMedæs tries to understand, address, and contained in this manual is intended for use by minimize the negative environmental effects that... - Page 6 Medical Vacuum Filter Modules Disposal of Materials Dispose contaminated substances and materials separately, according to local applicable environ- mental legislations. Dispose all components according to the appli- cable disposal regulations. 4107 9022 25.00...
-
Page 7: Installation
The condition of the MV Filter Module should be the Installation Diagram sent to you or download carefully inspected upon delivery. Any indication an electronic version from the website at of damage by the carrier should be noted on www.beaconmedaes.com. the delivery receipt, especially if the system will not be immediately uncrated and installed. The MV Filter Modules may remain in their Drain Flask Installation In- shipping containers until ready for installation. - Page 8 Medical Vacuum Filter Modules 3. Place one sealing washer over fitting. The second sealing washer is an extra. 5. Lastly, install the drain flask by screwing it onto the ball valve located on the bottom of the filter. Open the ball valve (handle in vertical position) before startup and during operation. 4. The finished assembly is now ready to be installed. The two arrow decals pictured above may or not be included. If so, discard. They are not required for this application.
-
Page 9: Operation
Medical Vacuum Filter Modules 3.0 Operation Precautions WARNING: Do not put MV Filter Module into operation until verified by a qualified person per NFPA 99, ISO 7396-1, or HTM 02-01. NFPA 99: 2018 Operational Procedure In order to comply with NFPA code, one filter must be in reserve at all times. This means that the but- terfly valves on both sides of one filter must be closed at all times. -
Page 10: Trouble Shooting
Medical Vacuum Filter Modules 4.0 Trouble Shooting Problem Possible Causes Solution Higher than usual differential Dirty filter element See maintenance schedule in section 5.2 pressure across the system or lower than usual flow through Too many filters offline See operational procedures in sections 3.2- the system 3.4 for the minimum required filters to be offline Blockages in system Inspect tubes for blockages Reduced vacuum level Leak(s) in system Check monthly for blockages and leaks in the system. If a leak is suspected, pressurize the system to maximum 30 psi and check for leaks. -
Page 11: Maintenance
The P/N for the kit is 4107 4018 65. More information can be found by referencing the Parts List. Please contact BeaconMedæs to have the Parts List sent to you or download an electronic version from the website at www.beaconmedaes.com. Close butterfly valves on both sides of filter being serviced. In addition to the PPE kit, below are the recommended gloves to be worn when servicing this equipment: Grainger P/N: 2VLZ8... - Page 12 The P/N for the flask is 4107 6558 95. More information can be found by referencing the Parts List. Please contact BeaconMedæs to have the Parts List sent to you or download an electronic version from the website at www.beaconmedaes.com. The drain flask is also suitable for steam sterilization up to 273 °F (134 °C) using hospital equipment and procedures. Valve shown in closed position...
- Page 13 Medical Vacuum Filter Modules 3. Open the ball valve to relieve the vacuum in the filter assembly and ease in removing the filter housing. 5. The picture above shows the filter housing unscrewed from the filter head and partially removed. 4. Unscrew the filter housing. A strap wrench will ease in loosening the filter housing. After the filter housing is loosened, it can be unscrewed by hand. 4107 9022 25.00...
- Page 14 (including double O-rings preinstalled) and filter housing O-ring. Each filter housing has a label specifying MV80 or MV160. For an MV80 filter, the kit P/N is 4107 4018 70. For an MV160 filter, the kit P/N is 4107 4018 71. More information can be found by referencing the Parts List. Please contact BeaconMedæs to...
- Page 15 Medical Vacuum Filter Modules 10. Install new filter by pressing firmly upwards into the filter head until the filter is seated. 12. Re-install the drain flask by screwing it onto the ball valve located on the bottom of the filter and re-open the butterfly valves on both sides of the filter. 13. Lastly, dispose of all contaminated PPE. 11. Install new filter housing O-ring that is provided with kit and re-install housing by fully tightening the housing onto the head.
-
Page 16: Maintenance Schedule
Medical Vacuum Filter Modules Maintenance Schedule Item Kit Part Number Recommended Maintenance Frequency MV80 Filter Element 4107 4018 70 Replace annually (*or as needed) MV160 Filter Element 4107 4018 71 Replace annually (*or as needed) Drain Flask 4107 6558 95 Replace with every filter element change Check monthly Differential Pressure 1629 0438 00 Gauge *If the gauge reads 0.4psi (≈30mbar) or more, change the filter element. Do so even if this occurs before a year has gone by before the filter element was changed last. If gauge is damaged, purchase Kit Part Number on the left. - Page 17 1059 Paragon Way, Rock Hill, SC 29730 (888) 4-MEDGAS (888) 463-3427 Fax: (803) 817-5750 www.beaconmedæs.com...
