TotalAlert Infinity™ HTM Medical Gas Notification System
Active Alarm Instruction:
To set facility instructions for active alarms, touch
either the GENERAL MESSAGE or OPTION MSG tab.
The alarm defaults to GENERAL MESSAGE. See Sec-
tion 4.6 for how to set up custom instructions.
G = High Alarm Settings Tab
Figure 42: High Alarm Settings Tab
You can remove the high alarm set point or customize
the high alarm set point.
To remove the high alarm set point:
1. Touch the NONE tab.
2. Touch the check on the CONFIRM SETTINGS
CHANGE screen.
To customize the high alarm set point:
1. Touch the ADJUST tab.
2. Enter the new set point.
3. Touch the Save button.
H = Zero Offset Tab
Figure 43: Zero Offset Tab
In some cases, facility dial gauges may show slightly
different readings than the TotalAlert Infinity™ alarm
(e.g., 3.2 BAR versus 3.0 BAR). To match the
TotalAlert Infinity™ alarm exactly to a facility dial gauge:
1. Select the offset amount.
2. Touch the Save button to close the screen.
Configuring Additional Gas Badges
Configure additional gas badges by touching the
number on the main configuration screen that
corresponds with the gas badge and repeating the
steps listed above.
4-13 4107 9016 60.01
