TotalAlert Infinity™ HTM Medical Gas Notification System
Figure 253
21. Then go to physical alarm screen.
22. Go to config screen.
23. Put in password.
Backspace
Figure 254
24. Touch Security Tab.
25. Touch Reboot Software Tab
(alarm will reboot - blinking led power light
while loading data)
4107 9016 60.01
Enter
Figure 255
26. If units of measure was setup from web-
site, then go to configuration screen and
choose the Area badge that requires the
website units. Choose E "units of measure"
then choose the units tab.
Close
Clear all
entered
text
9.2 Central Alarm Configuration -
Website
1. Accessing the Web Page.
Start a web browser such as
Chrome,FireFox,andSafari (Browser
needs to be able to interpret HTML5)
2. Enter the Device's IP address in the
browser's address bar:
Example: http://169.254.100.100
3. After you enter the IP address, the
alarm's home page will be
displayed. (See Figure 258)
9-6
Figure 256
Figure 257
