TotalAlert Infinity™ HTM Medical Gas Notification System
Active Alarm Instruction:
To set facility instructions for active alarms, touch
either the GENERAL MESSAGE or OPTION MSG tab.
The alarm defaults to GENERAL MESSAGE. See Sec-
tion 4.6 for how to set up custom instructions.
G = High Alarm Settings Tab
Figure 96: High Alarm Settings Tab
You can remove the high alarm set point or customize
the high alarm set point.
To remove the high alarm set point:
1.
Touch the NONE tab.
2.
Touch the check on the CONFIRM SETTINGS
CHANGE screen.
To customize the high alarm set point:
1.
Touch the ADJUST tab.
2.
Enter the new set point.
3.
Touch the Save button.
4107 9016 60.01
H = Zero Offset Tab
Figure 97: Zero Offset Tab
In some cases, facility dial gauges may show slightly
different readings than the TotalAlert alarm (e.g., 3.1
BAR versus 3.0 BAR). To match the TotalAlert alarm
exactly to a facility dial gauge:
1.
Select the offset amount.
2.
Touch the Save button to close the screen.
Configuring Additional Area Badges
Configure additional area badges by touching the
number on the numeric display that corresponds with
the area badge and repeating the steps listed above.
4-28
