TotalAlert Infinity™ HTM Medical Gas Notification System
Appendix A:
Variable B
Alarm Type and Size
Allowable Description
Value
B00 Blank
A10 Area Alarm, Up to 8 Area Gases
M01 Master, 0 Inputs, 16 Relay Outputs
M02 Master, 0 Inputs, 32 Relay Outputs
M10 Master, 20 Inputs
M11 Master, 20 Inputs, 16 Relay Outputs
C10 Combination, up to 20 Inputs, Display
up to 6 Area Gases
C40 Combination, 6 Relay Outputs and up
to 4 Inputs for 4-20mA devices
NOTE:
Standard configurations listed above. For special
configurations contact BeaconMedaes Customer
Service +44 (0) 1246 474 242.
Notes:
* Limitations on Combination Panels:
• C10, C11, C12 Combinations
x 0-10 source signal Inputs used, Display up to 6 Area gases
x 11-20 source signal Inputs used, Display up to 4 Area gases
• C40
x 0-20 source signal Inputs used, Display up to 4 4-20mA devices
x 21-27 source signal Inputs used, Display up to 2 4-20mA devices
Retrofit Alarm Models
A3- ___ - R
A
Available Gas Sensors
Description
Oxygen
Nitrous Oxide
Medical Air
Medical Vacuum
Nitrogen
Carbon Dioxide (CO2)
HE-O2 (HE over 80%)
Laboratory Air
Laboratory Vacuum
Surgical Air
O2-N2O
Example: TotalAlert Infinity™ Central Alarm with 20 Inputs and 16 Relay
Outputs
Example Model Number: A3-M11-R
Example: TotalAlert Infinity™ Area Alarm with four gases - Oxygen, Nitrous
Oxide, Medical Air, and Vacuum
Example Model Number: A3-A10-R
