Table 8.1. 10-Pin MSOP Dimensions

Dimension
C1
E
G1
X1
Y1
Z1
Notes:
General
1. All dimensions shown are in millimeters (mm) unless otherwise noted.
2. Dimensioning and Tolerancing per ASME Y14.5M-1994.
3. This Land Pattern Design is based on the IPC-7351 guidelines.
4. All dimensions shown are at Maximum Material Condition (MMC).
Least Material Condition (LMC) is calculated based on a Fabrication
Allowance of 0.05mm.
Solder Mask Design
1. All metal pads are to be non-solder mask defined (NSMD). Clearance
between the solder mask and the metal pad is to be 60 m minimum, all
the way around the pad.
Stencil Design
1. A stainless steel, laser-cut and electro-polished stencil with
trapezoidal walls should be used to assure good solder paste release.
2. The stencil thickness should be 0.125mm (5 mils).
3. The ratio of stencil aperture to land pad size should be 1:1.
Card Assembly
1. A No-Clean, Type-3 solder paste is recommended.
2. The recommended card reflow profile is per the JEDEC/IPC J-STD-
020 specification for Small Body Components.
MIN MAX
4.40 REF
0.50 BSC
3.00
— 0.30
1.40 REF
— 5.80
Rev. 1.0
Si4010-C2
—
25
