S i 4 7 0 4 / 0 5 / 0 6 / 0 7 / 1
A M / F M / S W / LW / W B R

1. Introduction

1.1. Scope

This document provides an overview of the programming requirements for the Si4704/05/06/1x/2x/3x/4x FM
transmitter/AM/FM/SW/LW/WB receiver. The hardware control interface and software commands are detailed
along with several examples of the required steps to configure the device for various modes of operation.

2. Overview

This family of products is programmed using commands and responses. To perform an action, the system
controller writes a command byte and associated arguments, causing the device to execute the given command.
The device will, in turn, provide a response depending on the type of command that was sent. "4. Commands and
Responses" on page 5 and "5. Commands and Properties" on page 6 describe the procedures for using
commands and responses and provide complete lists of commands, properties, and responses.
The device has a slave control interface that allows the system controller to send commands to and receive
responses from the device using one of three serial protocols (or bus modes): 2-wire mode (I
compatible), 3-wire mode, or SPI mode. "6. Control Interface" on page 168 describes the control interface in detail.
"7. Powerup" on page 176 describes options for the sequencing of VDD and VIO power supplies, selection of the
desired bus mode, provision of the reference clock, RCLK, and sending of the POWER_UP command.
"8. Powerdown" on page 182 describes sending the POWER_DOWN command and removing VDD and VIO
power supplies as necessary.
"9. Digital Audio Interface" on page 183 describes the digital audio format supported and how to operate the device
in digital mode.
"10. Timing" on page 186 describes the CTS (Clear to Send) timing indicating when the command has been
accepted and in most cases completed execution, and the STC (Seek/Tune Complete) timing indicating when the
Seek/Tune commands have completed execution.
"11. FM Transmitter" on page 191 describes the audio dynamic range control, limiter, pre-emphasis,
recommendations for maximizing audio volume for the FM transmitter.
"12. Programming Examples" on page 195 provides flowcharts and step-by-step procedures for programming the
device.
Confidential Rev. 0.2 2/08
Silicon Laboratories Confidential. Information contained herein is covered under non-disclosure agreement (NDA).
/ 2
/ 3
/ 4
F M T
X
X
X
X
P
EC EIVER
R O G R A M M IN G
Copyright © 2008 by Silicon Laboratories
/
R A N S M I T T E R
G
U I D E
AN332
2
C and SMBUS
AN332
