SFR Definition 34.10. TMR3L

Bit 7
Name
Type
0
Reset
SFR Address = 0xBC
Bit Name
Timer 3 Low Byte Actual Timer Value.
7:0 TMR3L[7:0]
In 16-bit mode, the TMR3L register contains the low byte of the 16-bit Timer 3. In 8-
bit mode, TMR3L contains the 8-bit low byte timer value.

SFR Definition 34.11. TMR3H

Bit 7
Name
Type
0
Reset
SFR Address = 0xBD
Bit Name
Timer 3 High Byte Actual Timer Value.
7:0 TMR3H[7:0]
In 16-bit mode, the TMR3H register contains the high byte of the 16-bit Timer 3. In 8-
bit mode, TMR3H contains the 8-bit high byte timer value.
6 5 4
TMR3L[7:0]
0 0 0
6 5 4
TMR3H[7:0]
0 0 0
Rev. 1.0
3 2
R/W
0 0
Function
3 2
R/W
0 0
Function
Si4010-C2
1 0
0 0
1 0
0 0
147
