SFR Definition 34.5. TMR2L

Bit 7
Name
Type
0
Reset
SFR Address = 0xCC
Bit Name
Timer 2 Low Byte Actual Timer Value.
7:0 TMR2L[7:0]
In 16-bit mode, the TMR2L register contains the low byte of the 16-bit Timer 2. In 8-
bit mode, TMR2L contains the 8-bit low byte timer value.

SFR Definition 34.6. TMR2H

Bit 7
Name
Type
0
Reset
SFR Address = 0xCD
Bit Name
Timer 2 High Byte Actual Timer Value.
7:0 TMR2H[7:0]
In 16-bit mode, the TMR2H register contains the high byte of the 16-bit Timer 2. In 8-
bit mode, TMR2H contains the 8-bit high byte timer value.
6 5 4
TMR2L[7:0]
0 0 0
6 5 4
TMR2H[7:0]
0 0 0
Rev. 1.0
3 2
R/W
0 0
Function
3 2
R/W
0 0
Function
Si4010-C2
1 0
0 0
1 0
0 0
