Si4010-C2

SFR Definition 27.1. PCON

Bit 7
Name
Type
0
Reset
SFR Address = 0x87
Bit Name
General Purpose Flags 5–0.
7:2 GF[5:0]
These are general purpose flags for use under software control.
Stop Mode Select.
1 STOP
Setting this bit will place the CIP-51 in Stop mode. This bit will always be read as 0.
1: CPU goes into Stop mode (internal oscillator stopped).
Idle Mode Select.
Setting this bit will place the CIP-51 in Idle mode. This bit will always be read as 0.
0 IDLE
1: CPU goes into Idle mode. (Shuts off clock to CPU, but clock to Timers, Interrupts,
Serial Ports, and Analog Peripherals are still active.)
102
6 5 4
GF[5:0]
R/W
0 0 0
Rev. 1.0
3 2
0 0
Function
1 0
STOP IDLE
R/W R/W
0 0
