Si4010-C2

SFR Definition 26.6. PORT_INTCFG

Bit 7
NEG_
Name
INT1
R/W
Type
0
Reset
SFR Address = 0xB7
Bit Name
Negative INT1 Polarity.
This bit selects whether the selected INT1 GPIO input will get inverted or pass as is
NEG_
before going to the edge detector. Note the edge detector detects either the rising
7
edge or both. The mode is selectable by EDGE_INT1 bit is separate register.
INT1
0: Pass the selected GPIO unchanged.
1: Inverts the selected GPIO.
INT1 Port Pin Selection Bits.
These bits select which Port pin is assigned to INT1.
000: Select GPIO0
001: Select GPIO1
SEL_ 010: Select GPIO2
6:4
INT1[2:0]
011: Select GPIO3
100: Select GPIO4
101: Select GPIO9
110: Select GPIO6
111: Select GPIO7
Negative INT0 Polarity.
This bit selects whether the selected INT0 GPIO input will get inverted or pass as is
NEG_
before going to the edge detector. Note the edge detector detects either the rising
3
edge or both. The mode is selectable by EDGE_INT0 bit is separate register.
INT0
0: Pass the selected GPIO unchanged.
1: Inverts the selected GPIO.
INT0 Port Pin Selection Bits.
These bits select which Port pin is assigned to INT0.
000: Select GPIO0
001: Select GPIO1
SEL_ 010: Select GPIO2
2:0
INT0[2:0]
011: Select GPIO3
100: Select GPIO4
101: Select GPIO8
110: Select GPIO6
111: Select GPIO7
100
6 5 4
SEL_INT1[2:0]
R/W
0 0 0
Rev. 1.0
3 2
NEG_ SEL_INT0[2:0]
INT0
R/W
0 0
Function
1 0
R/W
0 0
