Electrical Specifications - Oracle Acme Packet 6100 Hardware Installation Manual

Fan Module
Specifications

Electrical Specifications

Power Supply
Input Circuit Fuse
Requirements
Alarm Port Dry
Contact Current
Limits
90
Table 7 - 20. Acme Packet 6100 DC Power Supply Physical Dimensions
Specification
Depth
Weight
This table lists the fan module specifications for the Acme Packet 6100.
Table 7 - 21. Acme Packet 6100 Fan Module Specifications
Specification
Number of Fans
Total Maximum Airflow
Refer to the following tables for information regarding the electrical
specifications of the Acme Packet 6100.
This table lists the input circuit fuse and cable size requirements for the Acme
Packet 6100.
Table 7 - 22. Acme Packet 6100 Power Supply Input Circuit Fuse Requirements
Power Circuit Fuse Rating
120 VAC 15 AMP
240 VAC 10 AMP
-48 VDC 30 AMP
This table lists the alarm port electrical characteristics of the Acme Packet 6100.
Table 7 - 23. Acme Packet 6100 Alarm Port Dry Contact Current Limits
Specification
Max AC switching current
Max DC switching current
Description
13.26" (33.68 cm)
2lbs., 5 oz. (1.05 kg)
Description
5
100 CFM
Power cable size
18 AWG
18 AWG
12 AWG
Value
0.3 A @ 125 VAC
1 A @ 30 VDC
Acme Packet 6100 Hardware Installation Guide
