Reset Pushbutton
Power LED Alarm Silence Pushbutton
8
reset button, alarm LED, alarm silence button, console port, and USB port. The
following is a close up of the front control panel.
Figure 2 - 11. Acme Packet 6100 Front Control Panel
Pressing the front panel reset pushbutton will perform a hard reset of the
Acme Packet 6100, immediately rebooting the Acme Packet 6100. After the
reset button is released, the Acme Packet 6100 begins its boot sequence and
loads the configured software file.
The Acme Packet 6100 reset pushbutton button is recessed and can only be
pressed by inserting a thin wire (such as a paper clip) through the reset button
channel. Accidentally pressing the reset button can result in the loss of
software data or your configuration.
Alarm LED
Figure 2 - 12. Reset Pushbutton
Graphic Display Navigation Buttons
Acme Packet 6100 Hardware Installation Guide
Reset Pushbutton
