Graphic Display Output for HA Nodes

Initial State Displays
Out-Of-Service State
Displays
Becoming Standby
State Displays
Standby State
Displays
Active State Displays
Acme Packet 6100 Hardware Installation Guide
The information included in this section only applies to high availability Acme
Packet 6100 System nodes.
The graphic display on a Acme Packet 6100 in an HA node indicates the
current HA state. Five state indications can be displayed on the graphic
display. Only the Standby and Active state indications appear in the graphic
display for more than a few seconds. An explanation and example of each HA
state follows.
The following example shows the output in the graphic display window of a
Acme Packet 6100 in the initial state:
NET - NET
SESSION DIRECTOR (I)
The following example shows the output in the graphic display window of an
out-of-service Acme Packet 6100:
NET - NET
SESSION DIRECTOR (O/S)
The following example shows the output in the graphic display window of a
becoming standby Acme Packet 6100:
NET - NET
SESSION DIRECTOR (B/S)
The following example shows the output in the graphic display window of a
standby Acme Packet 6100:
NET - NET
SESSION DIRECTOR (S)
Acme Packet 6100 Systems in the active state use the default graphic display.
The following example shows the display of an active Acme Packet 6100:
NET - NET
SESSION DIRECTOR
