Link and SDP
Alarms
Media Ethernet Link
Alarms
Table 6 - 15. Media Ethernet Link Alarm Information
Alarm
Alarm Name
LINK UP ALARM 131073
10GIGPORT
LINK DOWN ALARM 131075
10GIGPORT
LINK UP ALARM 131109
10GIGPORT
LINK DOWN ALARM 131111
10GIGPORT
Management Ethernet
Link Alarms
Table 6 - 16. Management Ethernet Link Alarm Information
Alarm
Alarm Name
LINK UP ALARM 131077
VXINTF
LINK UP ALARM 131078
VXINTF
LINK UP ALARM 131079
VXINTF
LINK DOWN ALARM 131080
VXINTF
LINK DOWN ALARM 131081
VXINTF
LINK DOWN ALARM 131082
VXINTF
86
Link alarms are generated when a network cable is plugged into or unplugged
from a configured network interface. For each possible network interface, an
alarm exists that indicates whether the link goes up or down.
The following tables list detailed information about the Acme Packet 6100 NIU
link alarms, including their ID assignments, severities, causes, log messages,
and messages printed in the graphic display window.
The following table lists the NIU GigE link up/link down alarms.
Alarm Severity
ID
MINOR 10 GigE S0P0 link
up
MAJOR 10 GigE S0P0 link
down
MINOR 10 GigE S0P1 link
up
MAJOR 10 GigE S0P1 link
down
The following table lists the NIU management Ethernet port alarms.
Alarm Severity
ID
MINOR Mgmt0 link up
MINOR Mgmt1 link up
MINOR Mgmt2 link up
MAJOR Mgmt0 link down
MAJOR Mgmt1 link down
MAJOR Mgmt2 link down
Example Log
Cause(s)
Message
Slot 0 port 0 UP
Slot 0 port 0 DOWN
Slot 0 port 1 UP
Slot 0 port 1 DOWN
Example Log
Cause(s)
Message
Port 0 UP
Port 1 UP
Port 2 UP
Port 0 DOWN
Port 1 DOWN
Port 2 DOWN
Graphic Display Message
X LINK ALARMS (where X is num-
ber of alarming links)
X LINK ALARMS
X LINK ALARMS
X LINK ALARMS
Graphic Display Message
X LINK ALARMS (where X is num-
ber of alarming links)
X LINK ALARMS
X LINK ALARMS
X LINK ALARMS
X LINK ALARMS
X LINK ALARMS
