DC Power Supply Physical Dimensions

Table 7-3
(continued)
Specification
Height
Width
Depth
Weight
Important: This equipment is intended for installation in Network Telecommunication
Facilities.

Fan Module Specifications

Table 7-4
Specification
Number of Fans
Total Maximum Airflow

Electrical Specifications

Refer to the following tables for information regarding the electrical specifications of
the Acme Packet 6300/6350.

Power Supply Input Circuit Fuse Requirements

Table 7-5
Requirements
Power Circuit
120 VAC
240 VAC
-48 VDC

Alarm Port Dry Contact Current Limits

Table 7-6
Specification
Max AC switching current
Max DC switching current
Acme Packet 6300/6350 DC Power Supply Physical Dimensions
Acme Packet 6300/6350 Fan Module Specifications
Acme Packet 6300/6350 Power Supply Input Circuit Fuse
Fuse Rating
15 AMP
7.5 AMP
35 AMP min
Acme Packet 6300/6350 Alarm Port Dry Contact Current Limits
Electrical Specifications
Description
1.575" (4.0 cm)
2.146" (5.45 cm)
13.26" (33.68 cm)
2lbs., 0 oz. (1.05 kg)
Description
15
300 CFM
Power cable size
18 AWG
18 AWG
10 AWG
Value
0.3 A @ 125 VAC
1 A @ 30 VDC
Chapter 7
7-2
