Device Ratings

Environmental Specifications

Connector Specifications

Acme Packet 6100 Hardware Installation Guide
This table lists the alarm device ratings of the Acme Packet 6100.
Table 7 - 24. Acme Packet 6100 Device Ratings
Specification
AC 100- 240 VAC, 50-60 Hz, 5A (X2)
DC -48 VDC, 10 A (x2)
For the Acme Packet 6100 to function properly, Acme Packet recommends that
you follow the environmental guidelines in the following table.
Table 7 - 25. Acme Packet 6100 Environmental Specifications
Specification
Temperature The Acme Packet 6100 is required to operate within the temperature range
of:
+0° C to +40° C, 32° F to 104° F (operating)
-20° C to +65° C, -4° F to 149° F (storage)
Relative Humidity Operating conditions of 10% to 85% humidity under non-condensing operat-
ing conditions
Maximum Altitude The Acme Packet 6100 is required to operate below the maximum altitude
of 10,000 feet.
Air Flow 100 CFM
Heat Dissipation 500W (3796 BTU/hr) typical, 1000W (682 BTU/hr) maximum
Refer to the following table for information about the connector specifications
for the Acme Packet 6100.
Table 7 - 26. Acme Packet 6100 Connector Specifications
Specification
AC Connector Port
RJ45/Management Ethernet
Ports
RJ45/Alarm Contact Port
RS232/Serial Port
Value
Description
Description
The IEC lead connector port on each power supply accepts a 3-
lead IEC-60320 C14 connector for AC power installations (2)
The 3 x 8-pin RJ45 10/100/1000BaseT GigE ports are compliant
with IEEE's 802.3, 802.3u, and 802.3ab.
Any alarms generated by the system are accessible via the 8-pin
RJ45 alarm contact port.
The RS232 serial port uses an 8-pin RJ45 connector that supports
RS232-C protocol.
91
