DC Power Supply Physical Dimensions

This table lists the physical dimensions and weight of the Acme Packet 4600 DC
power supply.
Specification
Height
Width
Depth
Weight
Note:
This equipment is intended for installation in Network Telecommunication
Facilities.

Fan Module Specifications

This table lists the fan module specifications for the Acme Packet 4600.
Specification
Number of Fans
Total Maximum Airflow

Electrical Specifications

Refer to the following tables for information regarding the electrical specifications of
the Acme Packet 4600 System.

Power Supply Input Circuit Fuse Requirements

This table lists the input circuit fuse and cable size requirements for the Acme Packet
4600.
Power Circuit
120 VAC
240 VAC
-48 VDC

Alarm Port Dry Contact Current Limits

This table lists the electrical characteristics of the Acme Packet 4600 alarm port.
Description
1.575" (4.00 cm)
2.146" (5.45 cm)
13.26" (33.68 cm)
2lbs., 5 oz. (1.05 kg)
Description
5
100 CFM
Fuse Rating
15 AMP
7.5 AMP
30 AMP
Chapter 7
Electrical Specifications
Power Cable Size
18 AWG
18 AWG
10 AWG
7-2
