Display Modes

Base Display
Alarm Display

Graphic Display Menus

Top Menu
22
The Acme Packet 6100 graphic display defaults to one of two display modes:
Base display is the default and indicates a properly-functioning Acme
•
Packet 6100.
Alarm mode becomes the default display mode when any alarms are
•
active on the Acme Packet 6100. Active fault information is continuously
displayed on the graphic display.
The base display shows the type of Acme Packet 6100 running. This
information appears when the system first starts up and when the graphic
display times out at any menu level.
NET - NET
SESSION DIRECTOR
The base display of a Acme Packet 6100 in an HA node includes additional
information applicable to its HA state.
The alarm display replaces the base display during an alarm condition. The
alarm display informs you of what symptoms are currently causing alarms.
The number and type of alarms appear on the Acme Packet 6100 graphic
display, which indicates either a link alarm or a hardware alarm. For example,
if there are two link alarms present on the Acme Packet 6100, the display
appears like this:
2 LINK ALARMS
If the graphic display indicates an alarm condition, you can use the ACLI
display-alarms command to display the details of the alarm. When an alarm
condition is cleared, the base display replaces the alarm display. To clear an
alarm, you must execute the ACLI clear-alarm command or resolve the cause
of the alarm.
The Acme Packet 6100 graphic display lets you access the five display menus
for quick access to the system's current status.
The top menu provides top-level access to information in distinct categories of
system functionality.
To access the top menu from the base display or alarm display:
1. Press the Enter button. The first entry in the top menu appears.
2. Press the Up and Down buttons to scroll through the top menu categories.
The top menu rolls over when you reach the top or bottom of the menu.
