Electrical Installation
If fuses/Circuit Breakers according to recommendations are
chosen, possible damages on the frequency converter will
mainly be limited to damages inside the unit.
For further information see Application Note Fuses and
Circuit Breakers.

7.2.3 CE Compliance

Fuses or Circuit Breakers are mandatory to comply with IEC
60364. Danfoss recommend using a selection of the
following.
The fuses below are suitable for use on a circuit capable of
delivering 100,000 Arms (symmetrical), 240 V, 480 V, 500 V,
Enclosure Power [kW]
size
A1 0.25-1.5
A2 0.25-2.2
A3 3.0-3.7
B3 5.5
B4 7.5-15
C3 18.5-22
C4 30-37
A4 0.25-2.2
A5 0.25-3.7
B1 5.5-7.5
B2 11
C1 15-22
C2 30-37
Table 7.19 200-240 V, Frame Sizes A, B and C
RSPSupply - 1-888-532-2706 - www.RSPSupply.com
http://www.RSPSupply.com/p-21462-Danfoss-131B8966-VLT-Automation-VT-Drive-VFD-FC301-230V-5-HP.aspx
®
VLT AutomationDrive FC 300 Design Guide, 0.25-75 kW
Recommended Recommended
fuse size
gG-10
gG-10 (0.25-1.5)
gG-16 (2.2)
gG-16 (3)
gG-20 (3.7)
gG-25
gG-32 (7.5)
gG-50 (11)
gG-63 (15)
gG-80 (18.5) gG-150 (18.5)
aR-125 (22) aR-160 (22)
aR-160 (30) aR-200 (30)
aR-200 (37) aR-250 (37)
gG-10 (0.25-1.5)
gG-16 (2.2)
gG-10 (0.25-1.5)
gG-16 (2.2-3)
gG-20 (3.7)
gG-25 (5.5)
gG-32 (7.5)
gG-50
gG-63 (15) gG-160 (15-18.5)
gG-80 (18.5) aR-160 (22)
gG-100 (22)
aR-160 (30) aR-200 (30)
aR-200 (37) aR-250 (37)
®
MG33BE02 - VLT is a registered Danfoss trademark
600 V, or 690 V depending on the frequency converter
voltage rating. With the proper fusing the frequency
converter short circuit current rating (SCCR) is 100,000
Arms.
The following UL listed fuses are suitable:
•
UL248-4 class CC fuses
•
UL248-8 class J fuses
•
UL248-12 class R fuses (RK1)
•
UL248-15 class T fuses
The following max. fuse size and type have been tested:
Recommended circuit
Max. fuse breaker
Moeller
gG-25 PKZM0-16
gG-25 PKZM0-25
gG-32 PKZM0-25
gG-63 PKZM4-50
gG-125 NZMB1-A100
NZMB2-A200
NZMB2-A250
gG-32 PKZM0-25
gG-32 PKZM0-25
gG-80 PKZM4-63
gG-100 NZMB1-A100
NZMB2-A200
NZMB2-A250
Max trip level [A]
7
16
25
25
50
100
150
250
25
25
63
100
160
250
123
7
