Application Examples
FC
+24 V 12
+24 V 13
D IN 18
D IN 19
COM 20
D IN 27
D IN 29
D IN 32
D IN 33
D IN
37
+10 V 50
A IN
53
A IN
54
COM
55
A OUT
42
COM
39
Table 8.7 Start/Stop with Reversing and 4 Preset Speeds
FC
+24 V 12
+24 V 13
D IN 18
D IN 19
COM 20
D IN 27
D IN 29
D IN 32
D IN 33
D IN
37
+10 V 50
A IN
53
A IN
54
COM
55
A OUT
42
COM
39
Table 8.8 External Alarm Reset
RSPSupply - 1-888-532-2706 - www.RSPSupply.com
http://www.RSPSupply.com/p-21462-Danfoss-131B8966-VLT-Automation-VT-Drive-VFD-FC301-230V-5-HP.aspx
®
VLT AutomationDrive FC 300 Design Guide, 0.25-75 kW
Parameters
Function Setting
5-10 Terminal 18 [8] Start
Digital Input
5-11 Terminal 19 [10]
Digital Input Reversing*
5-12 Terminal 27 [0] No
Digital Input operation
5-14 Terminal 32 [16] Preset
Digital Input ref bit 0
5-15 Terminal 33 [17] Preset
Digital Input ref bit 1
3-10 Preset
Reference
Preset ref. 0 25%
Preset ref. 1 50%
Preset ref. 2 75%
Preset ref. 3 100%
*=Default Value
Notes/comments:
Parameters
Function Setting
5-11 Terminal 19 [1] Reset
Digital Input
*=Default Value
Notes/comments:
®
