Electrical Installation
Illustration 7.26 A5 - IP55
Hole Number
Dimensions
and
UL [in]
recommended
use
1) Mains
3/4
2) Motor
3/4
3) Brake/Load
3/4
Sharing
4) Control
3/4
Cable
5) Control
3/4
2)
Cable
6) Control
3/4
Cable
2)
Table 7.7 Legend to Illustration 7.26
± 0.2 mm
1)
Tolerance
2)
Knock-out hole
Illustration 7.27 A5- IP55 Threaded Gland Holes
Hole Number and recommended use
1) Mains
2) Motor
3) Brake/Load S
4) Control Cable
5) Control Cable
6) Control Cable
Table 7.8 Legend to Illustration 7.27
1)
Knock-out hole
RSPSupply - 1-888-532-2706 - www.RSPSupply.com
http://www.RSPSupply.com/p-21462-Danfoss-131B8966-VLT-Automation-VT-Drive-VFD-FC301-230V-5-HP.aspx
®
VLT
AutomationDrive FC 300 Design Guide, 0.25-75 kW
[3]
[4]
[5]
[6]
[2]
[1]
1)
[mm]
Nearest metric
28.4
M25
28.4
M25
28.4
M25
28.4
M25
28.4
M25
28.4
M25
[4]
[5]
[3]
[6]
[2]
[1]
Dimensions
M25
M25
1)
28.4 mm
M25
M25
M25
®
MG33BE02 - VLT
is a registered Danfoss trademark
Illustration 7.28 B1 - IP21
Hole Number
Dimensions
and
UL [in]
recommended
use
1) Mains
1
2) Motor
1
3) Brake/Load
1
Sharing
4) Control
1
Cable
5) Control
1/2
Cable
Table 7.9 Legend to Illustration 7.28
± 0.2 mm
1)
Tolerance
Illustration 7.29 B1 - IP55
Hole Number
Dimensions
and
UL [in]
recommended
use
1) Mains
1
2) Motor
1
3) Brake/Load
1
Sharing
4) Control
3/4
Cable
5) Control
1/2
Cable
5) Control
1/2
2)
Cable
Table 7.10 Legend to Illustration 7.29
± 0.2 mm
1)
Tolerance
2)
Knock-out hole
[1]
[4]
[5]
[3]
[2]
1)
[mm]
Nearest metric
34.7
M32
34.7
M32
34.7
M32
34.7
M32
22.5
M20
[5]
[4]
[3]
[6]
[2]
[1]
1)
[mm]
Nearest metric
34.7
M32
34.7
M32
34.7
M32
28.4
M25
22.5
M20
22.5
M20
119
7
7
