Danfoss VLT AutomationDrive FC 300 Design Manual page 105

How to Order
Power and Current Typical
Ratings motor
[kW] [A]* [kW]
PK37-P4K0 1-7,4 3
P5K5-P7K5 9,9+13 7,5
P11K 19 11
P15K 25 15
P18K 31 18,5
P22K 36 22
P30K 47 30
P37K 59 37
P45K 73 45
P55K 95 55
P75K 118 75
P90K 154 90
Table 5.18 440-480 V, 60 Hz
* HO ratings
Power and Current Typical
Ratings motor
[kW] [A]* [kW]
P11K 15 10
P15K 19 16.4
P18K 24 20
P22K 29 24
P30K 36 33
P37K 49 40
P45K 58 50
P55K 74 60
P75K 85 75
P90K 106 100
Table 5.19 600 V, 60 Hz
* HO ratings
Power and Power and Current
Typical
Current Ratings
motor
500-550 V
[kW] [A]* [kW]
P11K 15 7,5
P15K 19,5 11
P18K 24 15
P22K 29 18.5
P30K 36 22
P37K 49 30
P45K 59 37
P55K 71 45
P75K 89 55
P90K 110 75
Table 5.20 600 V, 60 Hz
* HO ratings
RSPSupply - 1-888-532-2706 - www.RSPSupply.com
http://www.RSPSupply.com/p-21462-Danfoss-131B8966-VLT-Automation-VT-Drive-VFD-FC301-230V-5-HP.aspx
®
VLT AutomationDrive FC 300 Design Guide, 0.25-75 kW
Filter current rating
50 Hz
[A]
10
14
19
25
31
36
48
60
73
95
118
154
Filter current rating
50Hz
[A]
15
20
24
29
36
50
58
77
87
109
Typical
Ratings
motor
551-690 V
[kW] [A]* [kW]
P15K 16 15
P18K 20 18.5
P22K 25 22
P30K 31 30
P37K 38 37
P45K 48 45
P55K 57 55
P75K 76 75
P90K 104 90
®
MG33BE02 - VLT is a registered Danfoss trademark
Ordering no AHF005
IP00 IP20
130B1787 130B1752
130B1788 130B1753
130B1789 130B1754
130B1790 130B1755
130B1791 130B1756
130B1792 130B1757
130B1793 130B1758
130B1794 130B1759
130B1795 130B1760
130B1796 130B1761
130B1797 130B1762
130B1798 130B1763
Ordering no AHF005
IP00 IP20
130B5261 130B5246
130B5262 130B5247
130B5263 130B5248
130B5263 130B5248
130B5265 130B5250
130B5266 130B5251
130B5267 130B5252
130B5268 130B5253
130B5269 130B5254
130B5270 130B5255
Filter current
rating Ordering no AHF005
50 Hz
[A] IP00
15 130B5000 130B5088
20 130B5017 130B5089
24 130B5018 130B5090
29 130B5019 130B5092
36 130B5021 130B5125
50 130B5022 130B5144
58 130B5023 130B5168
77 130B5024 130B5169
87 130B5170
130B5025
109 130B5026 130B5172
Ordering no AHF010
IP00 IP20
130B1770 130B1482
130B1771 130B1483
130B1772 130B1484
130B1773 130B1485
130B1774 130B1486
130B1775 130B1487
130B1776 130B1488
130B1777 130B1491
130B1778 130B1492
130B1779 130B1493
130B1780 130B1494
130B1781 130B1495
Ordering no AHF010
IP00 IP20
130B5229 130B5212
130B5230 130B5213
130B5231 130B5214
130B5231 130B5214
130B5233 130B5216
130B5234 130B5217
130B5235 130B5218
130B5236 130B5219
130B5237 130B5220
130B5238 130B5221
Ordering no AHF010
IP20 IP00 IP20
130B5297 130B5280
130B5298 130B5281
130B5299 130B5282
130B5302 130B5283
130B5404 130B5284
130B5310 130B5285
130B5324 130B5286
130B5325 130B5287
130B5288
130B5326
130B5327 130B5289
