Electrical Installation
7.3 Disconnectors and Contactors
7.3.1 Mains Disconnectors
Assembling of IP55/NEMA Type 12 (A5 housing) with
mains disconnector
Mains switch is placed on left side on frame sizes B1, B2,
C1 and C2. Mains switch on A5 frames is placed on right
side
Frame size
A5
B1
B2
C1 37 kW
C1 45-55 kW
C2 75 kW
C2 90 kW
Table 7.33 Terminal Connections for Various Frame Sizes
RSPSupply - 1-888-532-2706 - www.RSPSupply.com
http://www.RSPSupply.com/p-21462-Danfoss-131B8966-VLT-Automation-VT-Drive-VFD-FC301-230V-5-HP.aspx
®
VLT
AutomationDrive FC 300 Design Guide, 0.25-75 kW
Illustration 7.40 Location of Mains Switch
Type
Kraus&Naimer KG20A T303
Kraus&Naimer KG64 T303
Kraus&Naimer KG64 T303
Kraus&Naimer KG100 T303
Kraus&Naimer KG105 T303
Kraus&Naimer KG160 T303
Kraus&Naimer KG250 T303
®
MG33BE02 - VLT
is a registered Danfoss trademark
Terminal connections
L1
L2
L3
31
T1
T2
T3
32
L1
L2
L3
T1
T2
T3
7
7
43
44
13
14
131
