speed accuracy feedback and in high dynamic applications.
The encoder connection is either via term 32 and 33 or
encoder option MCB 102.
RCD
Residual Current Device.
Set-up
Save parameter settings in four Set-ups. Change between
the four parameter Set-ups and edit one Set-up, while
another Set-up is active.
SFAVM
Switching pattern called Stator Flux oriented Asynchronous
Vector Modulation (14-00 Switching Pattern).
Slip Compensation
The frequency converter compensates for the motor slip
by giving the frequency a supplement that follows the
measured motor load keeping the motor speed almost
constant.
Smart Logic Control (SLC)
The SLC is a sequence of user defined actions executed
when the associated user defined events are evaluated as
true by the Smart Logic Controller. (Parameter group 13-**
Smart Logic.
STW
Status Word
FC Standard Bus
Includes RS -485 bus with FC protocol or MC protocol. See
8-30 Protocol.
Thermistor:
A temperature-dependent resistor placed where the
temperature is to be monitored (frequency converter or
motor).
THD
Total Harmonic Distortion state the total contribution of
harmonic.
Trip
A state entered in fault situations, e.g. if the frequency
converter is subject to an over-temperature or when the
frequency converter is protecting the motor, process or
mechanism. Restart is prevented until the cause of the
fault has disappeared and the trip state is cancelled by
activating reset or, in some cases, by being programmed
to reset automatically. Trip may not be used for personal
safety.
Trip Locked
A state entered in fault situations when the frequency
converter is protecting itself and requiring physical
intervention, e.g. if the frequency converter is subject to a
short circuit on the output. A locked trip can only be
cancelled by cutting off mains, removing the cause of the
fault, and reconnecting the frequency converter. Restart is
prevented until the trip state is cancelled by activating
reset or, in some cases, by being programmed to reset
automatically. Trip may not be used for personal safety.
