Introduction
1-00 Configuration Mode determines what kind of
application control principle (i.e. Speed, Torque or Process
Control) is used when the remote reference is active.
1-05 Local Mode Configuration determines the kind of
application control principle that is used when the local
reference is active. One of them is always active, but both
3
3
can not be active at the same time.
3.3 Reference Handling
Local Reference
The local reference is active when the frequency converter
is operated with [Hand On] active. Adjust the reference by
▲
▼
[
]/[
] and [◄]/[►] navigation keys respectively.
22
RSPSupply - 1-888-532-2706 - www.RSPSupply.com
http://www.RSPSupply.com/p-21462-Danfoss-131B8966-VLT-Automation-VT-Drive-VFD-FC301-230V-5-HP.aspx
®
VLT
AutomationDrive FC 300 Design Guide, 0.25-75 kW
Remote Reference
The reference handling system for calculating the Remote
reference is shown in Illustration 3.9.
®
