Danfoss VLT AutomationDrive FC 300 Design Manual page 79

FC 300 Selection
Mains
Rise time
Cable voltage
length [m] [V] [μs]
30 240 0.300
100 240 0.536
150 240 0.776
Table 4.20 P30KT2
Mains
Cable voltage Rise time
length [m] [V] [μs]
30 240 0.300
100 240 0.536
150 240 0.776
Table 4.21 P37KT2
Mains
Cable voltage Rise time
length [m] [V] [μs]
5 480 0.640
50 480 0.470
150 480 0.760
Table 4.22 P1K5T4
Mains
Cable voltage Rise time
length [m] [V] [μs]
5 480 0.172
50 480 0.310
150 480 0.370
Table 4.23 P4K0T4
Mains
Rise time
Cable voltage
length [m] [V] [μs]
5 480 0.04755
50 480 0.207
150 480 0.6742
Table 4.24 P7K5T4
Mains
Rise time
Cable voltage
length [m] [V] [μs]
36 480 0.396
100 480 0.844
150 480 0.696
Table 4.25 P11KT4
RSPSupply - 1-888-532-2706 - www.RSPSupply.com
http://www.RSPSupply.com/p-21462-Danfoss-131B8966-VLT-Automation-VT-Drive-VFD-FC301-230V-5-HP.aspx
®
VLT AutomationDrive FC 300 Design Guide, 0.25-75 kW
du/dt
Upeak
[kV] [kV/μs]
0.598 1.594
0.566 0.844
0.546 0.562
Upeak du/dt
[kV] [kV/μs]
0.598 1.594
0.566 0.844
0.546 0.562
Upeak du/dt
[kV] [kV/μs]
0.690 0.862
0.985 0.985
1.045 0.947
Upeak du/dt
[kV] [kV/μs]
0.890 4.156
2.564
1.190 1.770
du/dt
Upeak
[kV] [kV/μs]
0.739 8.035
4.548
1.030 2.828
du/dt
Upeak
[kV] [kV/μs]
1.210 2.444
1.230 1.165
1.160 1.333
®
MG33BE02 - VLT is a registered Danfoss trademark
Mains
Rise time
Cable voltage
length [m] [V] [μs]
36 480 0.396
100 480 0.844
150 480 0.696
Table 4.26 P15KT4
Mains
Cable voltage Rise time
length [m] [V] [μs]
36 480 0.312
100 480 0.556
150 480 0.608
Table 4.27 P18KT4
Mains
Cable voltage Rise time
length [m] [V] [μs]
15 480 0.288
100 480 0.492
150 480 0.468
Table 4.28 P22KT4
Rise time
Cable Mains
length [m] voltage [μs]
5 480 0.368
50 480 0.536
100 480 0.680
150 480 0.712
Table 4.29 P30KT4
Mains
Rise time
Cable voltage
length [m] [V] [μs]
5 480 0.368
50 480 0.536
100 480 0.680
150 480 0.712
Table 4.30 P37KT4
Mains
Rise time
Cable voltage
length [m] [V] [μs]
15 480 0.256
50 480 0.328
100 480 0.456
150 480 0.960
Table 4.31 P45KT4
du/dt
Upeak
[kV] [kV/μs]
1.210 2.444
1.230 1.165
1.160 1.333
Upeak du/dt
[kV] [kV/μs]
2.846
1.250 1.798
1.230 1.618
Upeak du/dt
[kV] [kV/μs]
3.083
1.230 2.000
1.190 2.034
du/dt
Upeak
[kV] [kV/μs]
1.270 2.853
1.260 1.978
1.240 1.426
1.200 1.334
du/dt
Upeak
[kV] [kV/μs]
1.270 2.853
1.260 1.978
1.240 1.426
1.200 1.334
du/dt
Upeak
[kV] [kV/μs]
1.230 3.847
1.200 2.957
1.200 2.127
1.150 1.052
77
4 4
