Danfoss VLT AutomationDrive FC 300 Design Manual page 107

How to Order
Frequency converter ratings
525-600 V 690 V
[kW] Current [A] [kW]
0.75 1.7 1.1
1.1 2.4 1.5
1.5 2.7 2.2
2.2 3.9 3.0
3 4.9 4.0
4 6.1 5.5
5.5 9 7.5
7.5 11 11
11 18 15
15 22 18.5
18.5 27 22
22 34 30
30 41 37
37 52 45
45 62 55
55 83 75
75 100 90
90 131 -
Table 5.22 Sine Wave Filter 3x525-600 V
Frequency converter power rating: power ratings correspond to both HO and NO ratings. Changing the FC 300 to NO will change the operating
conditions.
Parameter
14-00 Switching Pattern
14-01 Switching Frequency
14-55 Output Filter
14-56 Capacitance Output Filter* Set according the individual filter. Listed at filter product label and in output filter manual.
14-57 Inductance Output Filter* Set according the individual filter. Listed at filter product label and in output filter manual.
Table 5.23 Parameter Settings for Sine-wave Filter Operation
* For Flux control principle.
RSPSupply - 1-888-532-2706 - www.RSPSupply.com
http://www.RSPSupply.com/p-21462-Danfoss-131B8966-VLT-Automation-VT-Drive-VFD-FC301-230V-5-HP.aspx
®
VLT AutomationDrive FC 300 Design Guide, 0.25-75 kW
525-550 V
Current [A] [kW] Current [A]
1.6
2.2
- -
3.2
4.5
5.5
7.5 - -
10
13 7.5 14
18 11 19
22 15 23
27 18 28
34 22 36
41 30 48
52 37 54
62 45 65
83 55 87
100 75 105
- 90 137
Setting
Select SFAVM.
Set according the individual filter. Listed at filter product label and in output filter manual. Sine-wave
filters are not allowing lower switching frequency than specified by the individual filter.
Select sine-wave fixed.
®
MG33BE02 - VLT is a registered Danfoss trademark
Switching
Filter current rating
Frequency
50 Hz 60 Hz 100 Hz
[A] [A] [A] kHz
4.5 4 3
10 9 7
13 12 9
28 26 21
45 42 33
76 72 57
115 109 86
165 156 124
Ordering no.
IP00 IP20/23*
4 130B7335 130B7356
4 130B7289 130B7324
3 130B3195 130B3196
3 130B4112 130B4113
3 130B4114 130B4115
3 130B4116 130B4117*
3 130B4118 130B4119*
2 130B4121 130B4124*
105
5 5
