How to Install

3.4.3 CE Compliance

Fuses or circuit breakers are mandatory to comply with IEC
60364. Danfoss recommends using a selection of the
following.
3 3
Enclosure
Size
B1
B2
B3
B4
C1
C2
C3
C4
Table 3.6 200-240 V, Frame Sizes B and C
Enclosure
Size
B1
B2
B3
B4
C1
C2
C3
C4
Table 3.7 380-500 V, Frame Sizes B and C
30
Operating Instructions VLT
Power Recommended
fuse size
[kW]
5.5-7.5 gG-25 (5.5)
gG-32 (7.5)
11 gG-50
5.5 gG-25
7.5-15 gG-32 (7.5)
gG-50 (11)
gG-63 (15)
15-22 gG-63 (15)
gG-80 (18.5)
gG-100 (22)
30-37 aR-160 (30)
aR-200 (37)
18.5-22 gG-80 (18.5)
aR-125 (22)
30-37 aR-160 (30)
aR-200 (37)
Power Recommended
fuse size
[kW]
11-15 gG-40
18.5-22 gG-50 (18.5)
gG-63 (22)
11-15 gG-40
18.5-30 gG-50 (18.5)
gG-63 (22)
gG-80 (30)
30-45 gG-80 (30)
gG-100 (37)
gG-160 (45)
55-75 aR-200 (55)
aR-250 (75)
37-45 gG-100 (37)
gG-160 (45)
55-75 aR-200 (55)
aR-250 (75)
®
MG34M302 - VLT
®
CDS302 and CDS303
The fuses below are suitable for use on a circuit capable of
delivering 100,000 Arms (symmetrical), 240V, 480V, 500V,
or 600V depending on the unit's voltage rating. With the
proper fusing, the frequency converter short circuit current
rating (SCCR) is 100,000 Arms.
Recommended
Max. fuse
gG-80
gG-100
gG-63
gG-125
gG-160 (15-18.5)
aR-160 (22)
aR-200 (30)
aR-250 (37)
gG-150 (18.5)
aR-160 (22)
aR-200 (30)
aR-250 (37)
Recommended
Max. fuse
gG-80
gG-100
gG-63
gG-125
gG-160
aR-250
gG-150 (37)
gG-160 (45)
aR-250
is a registered Danfoss trademark/Commercial Compressor
Recommended circuit Max trip level
breaker
Moeller
PKZM4-63
NZMB1-A100
PKZM4-50
NZMB1-A100
NZMB2-A200
NZMB2-A250
NZMB2-A200
NZMB2-A250
Recommended circuit Max trip level
breaker
Moeller
PKZM4-63
NZMB1-A100
PKZM4-50
NZMB1-A100
NZMB2-A200
NZMB2-A250
NZMB2-A200
NZMB2-A250
[A]
63
100
50
100
160
250
150
250
[A]
63
100
50
100
160
250
150
250
