Motor Bearing Currents - Danfoss VLT AutomationDrive FC 300 Design Manual

Electrical Installation
Frame Power Voltage 1 cable
Size Size [V] [m]
[kW]
A1, A2, 0.37-0.7 400 150
A5 5
500 150
A2, A5 1.1-1.5 400 150
500 150
A2, A5 2.2-4 400 150
500 150
A3, A5 5.5-7.5 400 150
500 150
B1, B2, 11-75 400 150
B3, B4,
500 150
C1, C2,
C3, C4
Table 7.35 Max. Cable Length for Each Parallel Cable, Depending
on Quantity of Parallel Cables.
Problems may arise at start and at low RPM values if motor
sizes are widely different because small motors' relatively
high ohmic resistance in the stator calls for a higher
voltage at start and at low RPM values.
The electronic thermal relay (ETR) of the frequency
converter cannot be used as motor protection for the
individual motor of systems with parallel-connected
motors. Provide further motor protection by e.g.
thermistors in each motor or individual thermal relays.
(Circuit breakers are not suitable as protection).
7.4.4 Motor Insulation
For motor cable lengths ≤ the maximum cable length
listed in 4.2 General Specifications, the following motor
insulation ratings are recommended because the peak
voltage can be up to twice the DC link voltage, 2.8 times
the mains voltage, due to transmission line effects in the
motor cable. If a motor has lower insulation rating it
recommended to use a dU/dt or sine wave filter.
Nominal Mains Voltage Motor Insulation
≤ 420 V Standard U
U
N
420V < U ≤ 500 V Reinforced U
N
500V < U ≤ 600 V Reinforced U
N
600V < U ≤ 690 V Reinforced U
N
Table 7.36 Motor Insulation
