Specifications

10.3 Fuse Specifications

10.3.1 CE Compliance

Fuses or circuit breakers are mandatory to comply with IEC 60364. Danfoss recommend using a selection of the following.
The fuses below are suitable for use on a circuit capable of delivering 100,000 Arms (symmetrical) with the following
voltage
•
240 V
•
480 V
•
600 V
•
690 V
depending on the drive voltage rating. With the proper fusing, the drive Short Circuit Current Rating (SCCR) is 100,000 Arms.

10.3.2 Fuse Tables

Enclosure Power (hp [kW])
A1 -
A2 0.34–3 [0.25–2.2]
A3 4–5 [3.0–3.7]
A4 0.34–3 [0.25–2.2]
A5 0.34–5 [0.25–3.7]
B1 7.5–15 [5.5–11]
B2 20 [15]
B3 7.5–15 [5.5–11]
B4 20–25 [15–18]
C1 25–40 [18.5–30]
C2 50–60 [37–45]
C3 30–40 [22–30]
C4 50–60 [37–45]
Table 10.12 200–240 V, Frame Sizes A, B and C
®
VLT AQUA Drive
Instruction Manual
Recommended
fuse size
gG-10
gG-10 (0.34–2 [0.25–1.5])
gG-16 (3 [2.2])
gG-16 (4 [3])
gG-20 (5 [3.7])
gG-10 (0.34–2 [0.25–1.5])
gG-16 (3 [2.2])
gG-10 (0.34–2 [0.25–1.5]}
gG-16 (3–4 [2.2–3])
gG-20 (5 [3.7])
gG-25 (7.5 [5.5])
gG-32 (10 [7.5])
gG-50
gG-25
gG-32 (10 [7.5])
gG-50 (15 [11])
gG-63 (20 [15])
gG-63 (20 [15]) gG-160 (20–25 [15–18.5)]
gG-80 (25 [18.5])
gG-100 (30 [22])
aR-160 (40 [30])
aR-200 (50 [37])
gG-80 (25 [18.5])
aR-125 (30 [22])
aR-160 (40 [30])
aR-200 (50 [37])
®
MG20M922 - VLT is a registered Danfoss trademark
Recommended Recommended circuit
Max. fuse breaker
Moeller
gG-25 PKZM0-16
gG-25 PKZM0-25
gG-32 PKZM0-25
gG-32 PKZM0-25
gG-32 PKZM0-25
gG-80 PKZM4-63
gG-100 NZMB1-A100
gG-63 PKZM4-50
gG-125 NZMB1-A100
NZMB2-A200
aR-160 (30 [22])
aR-200 (40 [30]) NZMB2-A250
aR-250 (50 [37])
gG-150 (25 [18.5]) NZMB2-A200
aR-160 (30 [22])
aR-200 (40 [30]) NZMB2-A250
aR-250 (50 [37])
Max trip level [A]
16
25
25
25
10
25
63
100
50
100
160
250
150
250
10-17
10
