Displaying System Information

Use the System Information screen to display descriptive information
about the switch, or for quick system identification as shown in the
following figure and table.
System Description : TigerStack 100 SMC6924MT
System Object ID
System Up Time
System Name
System Contact
System Location
<APPLY>
Use <TAB> or arrow keys to move, other keys to make changes.
Parameter
System Description
System Object ID
System Up Time
System Name*
System Contact*
System Location*
* Maximum string length is 255, but the screen only displays 45 characters. You can
use the arrow keys to browse the whole string.
2-8
C
ONFIGURATION
System Information
==================
: 1.3.6.1.4.1.202.20.6
: 48067 (0 day, 1 hr, 2min, 34 sec)
: DEFAULT SYSTEM NAME
: DEFAULT SYSTEM CONTACT
: DEFAULT SYSTEM LOCATION
Description
System hardware description.
MIB II object identifier for switch's network
management subsystem.
Length of time the current management agent has
been running. (Note that the first value is 1/100
second.)
Name assigned to the switch system.
Contact person for the system.
Specifies the area or location where the system
resides.
P
ROGRAM
<OK> <CANCEL>
