Management Setup Menu

After initially logging onto the system, adjust the communication
parameters for your console to ensure a reliable connection (Serial Port
Configuration). Specify the IP addresses for the switch (Network
Configuration / IP Configuration), and then set the Administrator and
User passwords (Console Login Configuration). Remember to record
them in a safe place. Also set the community string which controls access
to the on-board SNMP agent via in-band management software (SNMP
Configuration). The items provided by the Management Setup Menu are
described in the following sections.
Use <TAB> or arrow keys to move. <Enter> to select.
Menu
Network Configuration
Serial Port Configuration
SNMP Configuration
Console Login
Configuration
Management Setup Menu
=====================
Network Configuration ...
Serial Port Configuration ...
SNMP Configuration ...
Console Login Configuration ...
TFTP Download ...
Configuration Save & Restore ...
<OK>
Description
Includes IP setup, Ping facility, HTTP (Web
agent) setup, Telnet configuration, and MAC
address.
Sets communication parameters for the serial
port, including management mode, baud rate,
console time-out, and screen data refresh interval.
Activates traps; and configures communities and
trap managers.
Sets user names and passwords for system access,
as well as the invalid password threshold and
lockout time.
M
ANAGEMENT
S M
ETUP ENU
2-11
