S Ystem C Onfiguration; Using The System Configuration Program - SMC Networks TigerStack 100 1000BASE-X Management Manual

U S
SING THE YSTEM
You should define a new administrator password, record it and put it in a
safe place. Select Console Login Configuration from the Management
Setup Menu and enter a new password for the administrator. Note that
passwords can consist of up to 11 alphanumeric characters and are not
case sensitive.
Note: Based on the default configuration, a user is allowed three attempts
to enter the correct password; on the third failed attempt the
current connection is terminated.
After you enter the user name and password, you will have access to the
system configuration program as illustrated by the following menu
hierarchy:
System
Information Menu
Management
Setup Menu
Device
Control Menu
Network
Monitor Menu
System
Restart Menu
Exit
* Not implemented in this firmware release.
2-2
C
ONFIGURATION
System Information
Switch Information
Network Configuration
Serial Port Configuration
SNMP Configuration
Console Login Configuration
TFTP Download
Configuration Save & Restore
Management Configuration
Port Configuration
Port Information
Spanning Tree Configuration
Spanning Tree Information
Mirror Port Configuration
Port Trunking Configuration
IGMP Configuration
BStorm Control Configuration
Extented Bridge Configuration
802.1P Configuration
802.1Q VLAN Base Information
802.1Q VLAN Current Table Information
802.1Q VLAN Static Table Configuration
802.1Q VLAN Port Configuration
Port Security Configuration
Port GARP Configuration*
Port GMRP Configuration*
Port Statistics
RMON Statistics
Unicast Address Table
Multicast Address Registration Table*
IP Multicast Registration Table
Static Unicast Address Table Configuration
Static Multicast Address Table Configuration*
P
ROGRAM
IP Configuration
IP Connectivity Test(Ping)
HTTP Configuration
SNMP Communities
IP Trap Managers
STA Bridge Configuration
STA Port Configuration
STA Bridge Information
STA Port Information
802.1P Port Priority Configuration
802.1P Port Traffic Class Information
