Menu
Multicast Frames
CRC/Alignment Errors
Undersize Frames
Oversize Frames
Fragments
Jabbers
Collisions
64 Byte Frames
65-127 Byte Frames
128-255 Byte Frames
1024-1518 Byte Frames
Note: Statistics are automatically refreshed every five seconds (see page 2-17).
2-70
C
ONFIGURATION
Description
The total number of good frames received that were
directed to this multicast address.
The number of CRC/alignment errors (FCS or
alignment errors).
The total number of frames received that were less than
64 octets long (excluding framing bits, but including
FCS octets) and were otherwise well formed.
The total number of frames received that were longer
than 1518 octets (excluding framing bits, but including
FCS octets) and were otherwise well formed.
The total number of frames received that were less than
64 octets in length (excluding framing bits, but including
FCS octets) and had either an FCS or alignment error.
The total number of frames received that were longer
than 1518 octets (excluding framing bits, but including
FCS octets), and had either an FCS or alignment error.
The best estimate of the total number of collisions on
this Ethernet segment.
The total number of frames (including bad packets)
received and transmitted that were 64 octets in length
(excluding framing bits but including FCS octets).
The total number of frames (including bad packets)
received and transmitted that were between 65 and 127
octets in length inclusive (excluding framing bits but
including FCS octets).
The total number of packets (including bad packets)
received and transmitted that were between 128 and 255
octets in length inclusive (excluding framing bits but
including FCS octets).
The total number of packets (including bad packets)
received and transmitted that were between 1024 and
1518 octets in length inclusive (excluding framing bits
but including FCS octets).
