Configuring Broadcast Storm Control

Use the Broadcast Storm Control Configuration screen to enable
broadcast storm control for any port on the switch, as shown below.
<APPLY> <OK> <CANCEL> <PREV UNIT> <NEXT UNIT> <PREV PAGE> <NEXT PAGE>
Parameter
Broadcast control on all
ports
Threshold
Broadcast Control
2-50
C
ONFIGURATION
Broadcast Storm Control Configuration : Unit 1 Port
======================================
Broadcast control on all ports :
Port
-------------------------------------------------------
1
2
3
4
5
6
7
8
9
10
11
12
Use <TAB> or arrow keys to move. <Enter> to select
Description
Allows you to enable/disable broadcast storm control for
all ports on the switch.
The packet-per-second threshold at which broadcast
control will be employed on the port.
(Default is 500 pps.)
Enables/disables broadcast control for the port. When
enabled, the switch will employ a broadcast- control
mechanism if the packet-per-second threshold is
exceeded. This mechanism limits the amount of
broadcasts passed by the port to half of the received
packet-per-second count. The control mechanism
remains in effect until the number of received broadcasts
falls back below the packet-per-second threshold.
(Default is Enabled.)
P
ROGRAM
Threshold
500
500
500
500
500
500
500
500
500
500
500
500
1 - 12
[Enable] [Disable]
Broadcast Control
ENABLED
ENABLED
ENABLED
ENABLED
ENABLED
ENABLED
ENABLED
ENABLED
ENABLED
ENABLED
ENABLED
ENABLED
