Spanning Tree Configuration

The following figures and tables describe Bridge STA configuration.

Switch

Parameter
Usage
Priority

When the Switch Becomes Root

Parameter
Hello Time
Default Description
Enabled Enable this parameter to participate in an STA
compliant network.
32,768 Device priority is used in selecting the root device,
root port, and designated port. The device with the
highest priority becomes the STA root device.
(Remember that the lower the numeric value, the
higher the priority.) However, if all devices have the
same priority, the device with the lowest MAC
address will then become the root device.
Range: 0 - 65535
Default Description
2 The time interval (in seconds) at which the root device
transmits a configuration message.
The minimum value is 1.
The maximum value is the lower of
10 or [(Max. Message Age / 2) -1].
S T
PANNING REE
A (STA)
LGORITHM
3-25
