SMC Networks TigerStack 100 1000BASE-X Management Manual page 64

U S
SING THE YSTEM
You can use the Port Trunking Configuration screen set up port trunks as
shown below:
Trunk ID
---------
--
--
--
Trunk ID : 1
[Show]
[Enable]
Use <TAB> or arrow keys to move, other keys to make changes.
Parameter
Trunk ID
Status
Unit
Port
[Show]
[More]
[Enable] [Disable]
[Add] [Delete]
2-46
C
ONFIGURATION
Port Trunking Configuration
===========================
Status
-------- -----------
-------- Unit : -
Port : --
-------- Unit : -
Port : --
-------- Unit : -
Port : --
[More]
[Disable]
Description
Configure up to five trunks per switch.
Shows if the selected trunk is enabled or disabled.
Specifies a switch unit in the stack (1~4).
Select from 2 ~ 4 ports per trunk.
Displays trunk settings, where the first trunk listed is
specified by "Trunk ID."
Scrolls through the list of configured trunks.
Enables/disables the selected trunk.
Adds/deletes the port specified by
Trunk ID / Member Unit / Member Port.
P
ROGRAM
Member List
1 2
-----------
Unit : -
Port : --
Unit : -
Port : --
Unit : -
Port : --
Trunk ID : 1
[Add]
<OK>
3
----------- -----------
Unit : - Unit : -
Port : -- Port : --
Unit : - Unit : -
Port : -- Port : --
Unit : - Unit : -
Port : -- Port : --
Member Unit : 1
Member Port : 1
[Delete]
4
